KEYDIY KD-X2 KD X2 Key Programmer Remote Maker Unlocker Transponder Cloner

KEYDIY KD-X2 KD X2 Key Programmer Remote Maker Unlocker Transponder Cloner:

Thanks to the KEYDIY KD-X2 Key Programmer device, you will be able to create keydiy remotes, produce chips, and unlock locked remotes. You can create the control you want by coding more than 1000 control software to KEYDIY controls. It is an indispensable and indispensable auxiliary device for those who have a profession in the car key business. The KD-X2 device works by connecting to your mobile phone via Bluetooth. For this reason, you can use this device with both iPhone and Android compatible mobile phones. It is sufficient to have the “Mobile KD” application installed on your mobile phone.

Keydiy KD-X2 User Manual

KEYDIY KD-X2 Key Programmer Remote Maker Unlocker introduction:

1. Power supply: 2600mAh lithium battery; Charge method: USB 5V/1A

2. With 0.91inch OLED display screen.

3. Bluetooth BLE4.0 inside, work with mobile KD app by Bluetooth connection

4. Can work with PC software by USB-B connection, and work with Android phone or tablet by OTG connection.

5. With PS-2 interface for connecting remotes to generate.

6. Three functional shortcut buttons: chip identification, remote identification and frequency detection.

7. Basic functions as below:

• Wired Generation.

• Wireless Generation.

• Mobile Phone Simulation.

• Garage Door Generation.

• Proximity Key Unlock.

• 6 Frequency Detection.

• Infrared Detection.

• Access Card Copy.

• Fixed Code Remote Copy

• Online HCS Remote Copy.

• Online Chip Copy ( 96 bit 48chip, 46chip, 4Dchip, Toyota G chip etc. )

• Chip Generation.

• Chip Editing.

• Chip Simulation.

• Ignition Coil detection.

• Remote Data Backup.

• Additional Functions Will be Available in Succession.

• Free Activation of 96 Bits 48 Transponder Copy.

KEYDIY KD-X2 Features:

1. No tokens required for use
2. Keep up with free updates
3. Compatible with most manufactures chips in the market, such as baby, JMD,CN,VVDI etc.
4. Copy 96-bit (only) Copies chips (not full range per Keyoline Mini/884)
5. Online only works with a PC software connected via USB for functions
6. Eliminates the need to purchase many other devices
7. Transponder chip identification/to help choose the right chip to program
8. Remote identification to assist in deselection to program estimation studies
9. Frequency detection can also be used to check the correct operation of remote buttons
10. Ignition coil detection, check whether the vehicle itself sends a signal for fault testing

KEYDIY KD-X2 Supported car list:

• Benjin
• Bcahy
• Baojun
• Audi
• BMW
• Besturn
• Benz
• Cadillac
• Chang
• Changfeng
• Changhe
• Chevrolet
• Chrysler
• Citroen
• Daihatsu
• Dongfeng
• Faw
• Ford
• Garage
• Geely
• GMC
• Great Wall
• HaiMa
• Hawtai Motor
• Honda
• Isuzu
• Iveco
• Jaguar
• Land Rover
• Kia
• Jianghua
• Lincoln
• Mazda
• Mahindra
• MG
• Mitsubishi
• Opel
• Peugeot
• Citroen
• DS
• Porsche
• Proton
• Samand
• Renault
• Samand
• Ssangyong
• Skoda
• Subaru
• TATA
• Toyota
• Lexus
• VW

How to use KEYDIY KD-X2 to identify chip type?

Put the chip you want to identify in the chip slot, then press the “chip identification” button.

Current coverage of KEYDIY KD-X2 includes:

Transponder identification:

KDX2 can read and identify the following transponder types:

• Fixed code ID 11, 12, 13, 33 and 4C
• Philips Crypto 40, 41, 42, 44, 45, 46, 47, 49 and 4A
• Megamos 48, 48 Canbus
• Texas Crypto 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 6A, 6B, 70, 71, 72, 82, 83, 8C and 8E
• Smartest keys

Transponder cloning:

The KD-X2 offers a wide cloning range with built-in snoop for ID46 and ID48 cloning.
Currently, it can clone keys for KD-X2:

• 4D/ 4C / 46 / 11 / 12 / 13 / 33 transponder clone
• ID48 (96 Bit) only
• Fixed code (T5) using Carbon T5 chip – ID 11, 12, 13 & 33
• Texas TX 4C
• Texas Crypto TX /CR 4D
• Philips crypto PH/CR 46
• Toyota 80 Bit
• Megamos crypto

Transponder production:

The Keydiy KD-X2 also has a good range of transponder production
The transponder production coverage includes:

• ID4D / 60 / Epica60 / 61 / 62 / 63 / 64 / 65 / 66 / 67 / 68 / 69 / 6A / 71 / 72G 4C transponder
• ID48 type: seat TP22 / VAG TP23 / Skoda TP24 / Audi TP25/seat TA22 / VAG TA23 / Skoda
• TA24 / Audi TA25 / Fiat Fiat/Jetta ID48
• ID46 type: great wall (STEC) / Zotye (STEC) / Ha/ma (STEC) /maple (STEC) / Geely (SETC) /
• Cherry (STEC) / Zhonghua230 / Zhonghua530 / VW46 (2007-2008) /Trail (2008-2009)
• Renault (Maste.II) / Renault (Trafic II) / Opel (Vivaro) / Opel (Movano) / Renault (IV IV)
• Renault (Laguna II) / Renault (Velsatis) / Renault (Twingo) / Citroen / Fiat / Lancia / Peugeot (206/307)
• Mitsubishi / Cruze / Siemens / Changhe / Suzuki / GM / Beidouxing
• T5 type: 11 / 12 / 13 / 33
• ID47 type: Honda
• ID63 ford 80 bit

Signal test:

The KDX2 can check the frequency of a remote and determine the type (ie Ask or FSK), including:

• Frequency test (remote, ASK/FSK)
• ECU signal test (check if the coil is working)

Simulator:

To ensure correct operation before cloning a chip, the KD-X2 allows you to simulate the key before copying:

• ID46
• ID4D

Transponder Edit:

The KDX2 allows you to read, write and edit chip data on 4D / 46 / 48 / 47 / 4D DST/8A etc

KEYDIY KD-X2 Remote Maker Unlocker Package List:

• 1 x remote maker
• 1 x PC data cable
• 3 x Keydiy universal remotes
• 1 x remote data cable
• 1 x Spare Remote generating cable
• 1 x user manual
