GP High Voltage 23A V23GA MN21 Ultra Alkaline Battery 12V

GP High Voltage 23A V23GA MN21 Ultra Alkaline 12V Battery – Features, Uses, and Comparison:

The GP 23A Ultra Alkaline Battery is a high-voltage, compact cylindrical cell designed for devices that require stable and long-lasting power. With its 12V output, it is widely used in remote controls, key fobs, alarms, and garage door openers, ensuring efficient radio frequency transmission.

In this guide, we’ll explore the features, specifications, applications, and a comparison between GP 23A and 27A batteries, helping you determine the best option for your device.

1. What is the GP 23A Battery?

The GP 23A battery is a non-rechargeable, high-voltage alkaline battery commonly used in devices requiring a compact power source. Thanks to its stable voltage output and high energy density, it delivers consistent performance in wireless remote controls, key alarms, and security devices.

It is compatible with multiple battery codes, including MN21, A23, GP23A, AG23, L1028, VR22, V23GA, GP23AE, 3LR50, K23A, LRV08, and E23A.

2. Battery Size 23A Specifications

Below are the key specifications of the GP 23A Ultra Alkaline Battery:

• Manufacturer: GP
• Model Number (MPN): 23AEC5
• Country of Origin: China
• Voltage: 12V
• Capacity: 38mAh (at 20kΩ load)
• Battery Type: Ultra Alkaline
• Common Applications: Remote controls, key fobs, alarms
• Rechargeable: No
• Height: 28.5mm
• Diameter: 10.22mm
• Associated Battery Sizes: 1811A, 21/23, 23A, GP23A, L1028, MN21, V23GA

3. Common Applications of the GP 23A Battery – Battery Size 23A:

The GP 23A battery is widely used in electronic devices requiring high-voltage output and a compact form factor.

✅ Popular Applications Include:

• Remote Controls – TV remotes, garage door openers, car key fobs
• Security Devices – Wireless alarm systems, motion sensors
• Medical Devices – Glucose monitors, electronic thermometers
• Household Gadgets – Digital door locks, wireless doorbells
• Toys & Gadgets – RC (remote-controlled) toys, wireless transmitters

Its high voltage (12V) ensures optimal transmission power, making it ideal for wireless communication-based devices.

4. Difference Between GP 23A and 27A Batteries

Many users often compare GP 23A and GP 27A batteries due to their similar voltage (12V), but they have significant differences in size, capacity, and weight.

Key Differences:

• Size: The 23A battery is wider (10.22mm), while the 27A battery is slimmer (8.0mm).
• Capacity: The 23A battery offers 38mAh, whereas the 27A has a lower capacity of 18mAh.
• Compatibility: The 23A battery may not fit in devices designed for a 27A due to its larger size.

💡 Pro Tip: If your device specifically requires a 27A battery, do not replace it with a 23A, as it may not fit correctly.

5. Can a GP 23A Battery (Battery Size 23A) Replace a 27A Battery?

This is a common question among users. While both batteries operate at 12V, the GP 23A battery (Battery Size 23A) has a larger diameter than the 27A battery.

• If your device requires a 27A battery, a 23A battery might not fit properly.
• If your device accepts a slightly larger battery slot, you may use a 23A instead of a 27A, but it’s not recommended unless explicitly mentioned in the device manual.

🔧 Always check your device’s battery specifications before making a replacement.

GP 23A Alkaline Battery Data Sheet

GP Button Cell & Miniature Alkaline Batteries MSDS
